Rhino 512 console

PRODUCT SEREIS



Desription:

DMX512/1990 standard, 512 DMX control channels.
4 output with optical isolated , with stand 2000 Vrmms.
Up to 50 SHAPE generators. SHAPE track control is provided to control such effects as circles, lines and shapes like 8, etc.
Up to 32 scanners may be connected with a maximum of 16 channels each.
A large backlight LCD to display operation parameters.
16 channel faders plus 1 speed and 1 cross control fade.
1600 chase steps, 48 chases, up to 99 steps each. Each step contains its speed and cross time, can be set respectively. Trigger mode selectable: Music synchronously and manual speed.
The time range of both SPEED fade and CROSS fade is 0.01s-25.5s and the total time amount of current status will be program step time
48 scanner scenes can be used directly.
8 chases, 48 scenes operated at the same time. At most 32 scanners can be selected
The X/Y channels of different scanners can be controlled by modulation wheel.
16Bit control for absolutely precise movement.
15 environment programsto output the combination,which are composed of different scenes,chases and manual output quickly.
The music trigger source can be selected between audio line input or inside microphone.
Easy to edit and handle.
The Data auto-saves.
High performance switching power supply, with extremely low power harmonious distortion and wide range of voltage, suit for the requirement of different country.  simultaneously.
LED lamp connector
Power input: DC9V 1000mA
Dimension: 498 × 420 × 115mm
Net Weight: 6.3kg

Model: YX-CL1325
