4 EYES RGB LASER

PRODUCT SEREIS



Click on Video Link

Desription:

6 head RGB animation laser array. Around 100 laser patterns and beam effects built-in。 Customers can use DMX controller to control each head separately (patterns, effects, color, dimming, position, etc.), so as to get same effects or different effects laser show.
Dust proof designs. IP rate is IP61. Can prevent the dust and fog machine oil into machine. Prolong the laser life and reduce the maintenance costs.
More stable and better performance full diode RGB laser module. Working temperature is -30°C-40°C.
Analog modulation laser modules. Can dimmer the laser output power from 0% to 100% linearly so as to reach millions of colors.
Modern LCD display technology. Easy to understand the pattern size, sound sensitive, color, scanner speed, mirror setting.
Play mode: Sound active, Auto, Master/Slave, DMX normal (12 channels), DMX professional (62 channels).
Safety: Key lock, remote interlock, safety ring
Power: 100~250V,50/60HZ
Application: Family party, club, laser show, etc.
Specification:
Red Power: 50mW*4PCS
Wavelength:638nm
Divergence:<1.2mrad
Green Power:>50mW*4PCS
Wavelength:532nm
Divergence:<1.2mrad
Blue Power:150mW*4PCS
Wavelength:450nm
Divergence:<1.2mrad
Scanner: 20KPPS ±20°
650*180*100mm (H)mm


Model: YX-A410RGB
