HOME    MOVING HEAD    400W LED 3 in 1 BSW Moving Head light CMY+CTO

400W LED 3 in 1 BSW Moving Head light CMY+CTO

PRODUCT SEREIS



Description:

Color temperature: 8000K Color rendering index: 75
Input voltage: AC110V-240V/50-60HZ
Light source specification: 400W white light LED module
Light source lifespan: 50000 hours
Luminous illumination: 4 meters 80000 lm
Rated power: 430W
Channel mode: 22 channels
Horizontal scanning: 540 degrees (16 bit precision scanning) electronic error correction
Vertical scanning: 270 degrees (16 bit precision scanning) electronic error correction
Dimming system: 0-100% linear adjustment
Focusing system: linearly adjustable from 4 meters to 50 meters
Atomization system: 1 independent atomization effect, soft and natural light spot
Magnification angle: 4-35 degrees
High speed strobe: 0-30 times/second. Adjustable speed strobe effect. Strobe macro function
Color: 12 colors+white light. Color half color function
Color system: an independent CMY+CTO color mixing system.
Fixed pattern: 12 fixed patterns+white light
Rotating pattern: 7 glass patterns, each of which can be independently reversed
Prism system: standard with single 6-row prisms and 8? 8 prisms, each prism can independently forward and reverse
Macro functions: console reset function, self driving mode, master-slave mode
Display mode: LCD display, button+touch dual operation mode
Control signal: International standard DMX512. Equipped with RDM function, can upgrade online software, dial address code
Cooling method: using axial fans to enhance cooling
Safety device: equipped with electronic temperature control overheat protection, the electronic temperature control automatically power-off protection in case of overheat system failure
Appearance material: High temperature resistant plastic
Working environment: -20 degrees, 40 degrees
Protection level: IP20
Net weight of product: 22.5KG
Product size: 38 * 27 * 65CM (L * W * H)

Model: YX-MH400B
